We are Manufacturer, Supplier, Exporter of: Hydraulic Workshop Type Press (WTH-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Single acting spring return / Double acting oil return
- Cylinder honed to a surface finish of 0.4 microns.
- Hard chrome plated ram to resist scoring and corrosion.
- Wiper to arrest ingress of foreign particles.
- Working pressure 450-700 Bar
- Operated by hand Pump / Power pack
- Mechanical winch and 'V' blocks shall be provided up to 100 T capacity presses only.
Technical Specification :
Model |
Capacity |
Stroke 'A' |
Min.Daylight 'B' |
Max Daylight 'C' |
Daylight setting 'D' |
Width between Column 'E' |
Depth between Column 'F' |
Overall size G x H x L |
Weight Approx. |
Tons |
MM |
MM |
MM |
MM |
MM |
MM |
MM |
KGS. |
|
WTH-10 |
10 |
150 |
200 |
650 |
150 |
600 |
150 |
1000 x 1500 x 500 |
180 |
WTH-15 |
15 |
150 |
200 |
650 |
150 |
600 |
150 |
1000 x 1500 x 500 |
200 |
WTH-25 |
25 |
150 |
200 |
650 |
150 |
800 |
150 |
1200 x 1700 x 600 |
250 |
WTH-40 |
40 |
150 |
200 |
800 |
150 |
915 |
200 |
1500 x 1900 x 600 |
500 |
WTH-50 |
50 |
150 |
200 |
800 |
150 |
915 |
200 |
1500 x 1900 x 700 |
550 |
WTH-75 |
75 |
150 |
250 |
1050 |
200 |
915 |
250 |
1600 x 2100 x 700 |
600 |
WTH-100 |
100 |
150 |
250 |
1050 |
200 |
1015 |
300 |
1700 x 2300 x 800 |
900 |
WTH-150 |
150 |
150 |
250 |
1050 |
200 |
1015 |
350 |
1800 x 2400 x 1000 |
1200 |
WTH-200 |
200 |
150 |
250 |
1050 |
200 |
1015 |
400 |
1850 x 2400 x 1000 |
1500 |
