Capacity : 30-300 tons, Stroke : 100-150 mm, Working : 700 bar (Max)
We are Manufacturer, Supplier, Exporter of: Plain Ram Center Hole, Double Acting Hydraulic Jacks (CHD-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- High strength, Heat treated alloy steel body.
- Hard chrome plated ram to resist scoring and corrosion.
- Double acting for push pull application.
- Wiper to arrest ingress of foreign particles.
- Bigger center hole allows to run screws / cables / studs to pull or push forces.
- High pressure long life seals.
- QCC with plastic dust cap.
- Aluminum Dust Cap on Request.
- Bottom mounting holes for fixturing different types of puller attachments.
- Customised Higher capacity, strokes available on request.
- Port Size 3/8" NPT.
Application :
Technical Specification :
These jacks are designed to attach various puller attachments for removing gears, bearings, Pulleys, pre-stressing at construction projects.
Technical Specification :
MODEL NO. |
For Ton |
Ret Ton |
Closed Ht. 'CH' |
Stroke 'S' |
Center Hole Dia 'CH' |
Ram Dia 'RD' |
Outer Dia 'D' |
Forward volume |
Return
Volume |
Approx
Weight |
Suitable
Hand Pump |
tons. |
tons. |
mm. |
mm. |
mm. |
mm. |
mm. |
cc. |
cc. |
kgs. |
||
CHD-30/100 |
30 |
6.7 |
270 | 100 |
34 |
75 |
120 |
490 |
278 |
19.0 |
PHP-400/3DCV |
CHD-30/150 |
30 |
6.7 |
295 |
150 |
34 |
75 |
120 |
726 |
411 |
22.0 |
PHP-400/3DCV |
CHD-50/100 |
50 |
8.2 |
280 |
100 |
42 |
95 |
150 |
786 |
343 |
28.0 |
PHP-500/6DCV |
CHD-50/150 |
50 |
8.2 |
330 |
150 |
42 |
95 |
150 |
1162 |
508 |
31.0 |
PHP-500/6DCV |
CHD-60/100 |
60 |
12.0 |
290 |
100 |
54 |
110 |
160 |
966 |
500 |
35.0 |
PHP-500/6DCV |
CHD-60/150 |
60 |
12.0 |
305 |
150 |
54 |
110 |
160 |
1430 |
741 |
40.0 |
PHP-500/6DCV |
CHD-80/100 |
80 |
15.9 |
60 |
120 |
190 |
1328 |
190 |
1328 |
668 |
51.0 |
PHP-500/6DCV |
CHD-80/150 |
80 |
15.9 |
360 |
150 |
60 |
120 |
190 |
1960 |
986 |
60.0 |
PHP-500/6DCV |
CHD-100/100 |
100 |
18.2 |
320 |
100 |
70 |
140 |
205 |
1639 |
767 |
57.0 |
PHP-500/6DCV |
CHD-100/150 |
100 |
18.2 |
370 |
150 |
70 |
140 |
205 |
2404 |
1125 |
70.0 |
PHP-500/6DCV |
CHD-150/150 |
150 |
34.4 |
415 |
150 |
80 |
150 |
260 |
3413 |
2061 |
150 |
PHP-500/12DCV |
CHD-200/150 |
200 |
54.2 |
435 |
150 |
90 |
180 |
300 |
5646 |
3254 |
165 |
PHP-500/12DCV |
CHD-300/150 |
300 |
64.5 |
450 |
150 |
110 |
200 |
330 |
4825 |
2713 |
220 |
PHP-500/16DCV |
