Capacity : 5-200, Stroke : 8-16 mm, Working : 700 bar (Max)
We are Manufacturer, Supplier, Exporter of: Ultra Low Height Plain Ram Spring Return Hydraulic Flat Jacks( FJS Series ) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Compact, Flat design, High strength, heat treated alloy steel body
- Hard chrome plated ram to resist scoring & corrosion.
- Single acting, spring return for smooth lowering. High pressure long life seals.
- Top mounting holes for easy fixturing. Grooved ram acts as integral saddle.
- 'O' Ring to arrest ingress of foreign particles.
- Poet Size 1/4th Inch or 3/8" NPT.
- QCC with Plastic dust cap. Aluminium dust cap on request.
Technical Specification :
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer
Dia 'D' |
Oil Volume |
Approx Weight |
Suitable
Hand Pump |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
kgs. |
||
FJS 5/8 |
5 |
35 |
8 |
25 |
60 x 45 |
7.2 |
0.5 |
PHP 200 / 2 |
FJS
5/16 |
5 |
43 |
16 |
25 |
60 x 45 |
12.9 |
1.0 |
PHP 200 / 2 |
FJS 10/12 |
10 |
45 |
12 |
38 |
80 x 60 |
19 |
1.3 |
PHP 200 / 2 |
FJS
20/12 |
20 |
51 |
12 |
50 |
100 x 80 |
40.5 |
2.6 |
PHP 200 / 2 |
FJS
30/12 |
30 |
58 |
12 |
65 |
117 x 95 |
57.5 |
3.0 |
PHP 200 / 2 |
FJS
50/16 |
50 |
65 |
16 |
70 |
140 x 120 |
113.5 |
6.0 |
PHP 400 / 3N |
FJS
75/16 |
75 |
79 |
16 |
85 |
175 x 145 |
203.5 |
11.6 |
PHP 400 / 3N |
FJS
100/16 |
100 |
85 |
16 |
100 |
185 x 160 |
257 |
17.1 |
PHP 400 / 3N |
FJS
150/16 |
150 |
85 |
16 |
120 |
230 x 205 |
408.5 |
29.5 |
PHP 400 / 3N |
FJS
200/16 |
200 |
115 |
16 |
140 |
265 x 230 |
510.3 |
45.0 |
PHP 400 / 3N |
