We are Manufacturer, Supplier, Exporter of: Hydraulic Toe Jack / Machine Lifts (HTJ-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- High strength, Heat treated alloy steel body for better life.
- Hard chrome plated ram to resist Corrosion.
- Single acting load return.
- High pressure long life seals. QCC with dust cap.
- Adequate gripping by grooved saddles. Precise machined body for smooth operation.
- Wiper to arrest ingress of foreign particles
- Easy adjustable toe fixing positions for different heights and strokes.
- High pressure long life seals. QCC with Plastic dust cap. Aluminium Dust Cap on Request.
- Advantage to use single or multiple jack with common hand pump.
- Adjustable legs for extra grip. Castor wheels for easy mobility in new version.
- Port Size 3/8" NPT.
Application :
Technical Specification :
These jacks are used for lifiting of heavy machineries, transformers, structural equipment etc.
Technical Specification :
MODEL |
Capacity |
Toe Clearance |
Stroke |
Toe Height at Max. Position |
Total Body Max. Height |
Approx Weight |
tons. |
mm. |
mm. |
mm. |
mm. |
mm. |
|
HTJ 5 |
5 |
20 |
150 |
320 |
320 |
25 |
HTJ 10 |
10 |
25 |
150 |
355 |
355 |
40 |
HTJ 20 |
20 |
40 |
150 |
385 |
380 |
65 |
