Capacity : 50 - 150 tons, Stroke : 100 - 160 mm, Working : 700 bar (Max)
We are Manufacturer, Supplier, Exporter of: Aluminium Double Acting, Plain Ram, Hydraulic Jacks ( ADP-Series ) from Belgaum, Karnataka, India.
Features / Benefits :- High strength, light metal Aluminium alloy body for longevity.
- Bore is roller burnished for work hardened smooth surface.
- Double acting for quicker retraction to get ready for next operation.
- Scraper / Wiper to arrest ingress of foreign particles.
- Safety valve to prevent pressure intensification in the annular area.
- Replaceable hardened steel saddle to prevent denting & bulging of ram head.
- Larger steel base for stability.
- Ergonomic handles to ease handling.
- Bottom mounting holes meant for fixturing the steel base & not to be removed.
- Golden ring prevents overshoot of ram. Golden ring withstands full load of the jack.
- Customised Higher capacity, strokes available on request.
- Quick connect couplers with plastic dust caps. Aluminium dust cap on request.
- Port size 3/8th inch NPT.
Application :
Technical Specification :
For lifting loads at elevated location where weight of the jack is a concern. Force available in either direction and can be used horizontally also.These jacks are for maintenance purpose only and not for production
Technical Specification :
MODEL NO. |
Cap. Fwd. |
Cap. Rtn. |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Forward volume |
Return volume |
Approx Weight |
Suitable Hand Pump |
tons. |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
kgs. |
|||
ADP-50/100 |
50 |
18 |
265 |
100 |
80 |
155 |
720 |
270 |
15 |
PHP-500/6 DCV |
ADP-50/150 |
50 |
18 |
315 |
150 |
80 |
155 |
1080 |
420 |
20 |
PHP-500/6 DCV |
ADP-100/100 |
100 |
44 |
325 |
100 |
100 |
195 |
1450 |
810 |
25 |
PHP-500/6 DCV |
ADP-100/150 |
100 |
44 |
375 |
150 |
100 |
195 |
2150 |
1200 |
30 |
PHP-500/6 DCV |
ADP-150/100 |
150 | 77 |
340 |
100 |
120 |
240 |
3100 |
1670 |
43 |
PHP-500/16 DCV* |
ADP-150/150 |
150 |
77 |
390 |
150 |
120 |
240 |
3420 |
1990 |
50 |
PHP-500/12 DCV* |
*PP-Power Pack |
||||||||||
