We are Manufacturer, Supplier, Exporter of: Hydraulic Telescopic Jacks (PTJ - Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Telescopic design, heat treated alloy steel body.
- Hand chrome plated rams to resist scoring and corrosion
- Single acting load return. High pressure long life seals.
- 'o' Ring to arrest ingress of foreign particles
- Port Size 3/8 inch NPT.
- QCC with Plastic dust cap. Aluminium dsut Cap on Request
Application :
Technical Specification :
Telescopic jacks are specially designed where space is a constraint and higher stroke is desired ideally used for lifiting of heavy machinery etc.
Technical Specification :
|
MODEL NO.
|
Capacity
|
Closed Ht. 'CH'
|
Spread
|
Total Stroke
|
Outer Dia of Jack
|
|
|
tons.
|
mm.
|
mm.
|
mm.
|
mm.
|
mm.
|
|
| PTJ-20/350 | 20 | 350 | 175 | 175 | 350 | 135 |
| PTJ-50/350 | 50 | 350 | 175 | 175 | 350 | 170 |
