Capacity : 5 - 500 tons, Stroke : 50 - 150 mm, Working : 700 bar
(Max)
We are Manufacturer, Supplier, Exporter of: Plain Ram, Springs Return Hdraulic Jacks (LPS-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Hight strength, Heat treated alloy steel body
- Hard chrome plated ram to resist scoring and corrosion.
- Single acting spring return for smooth lowering.
- High pressure long life seals.
- Wiper to arrest ingress of foreign particles.
- Bootom mounting holes for bolting.
- Adequate gripping by grooved saddle.
- Port Sixe 3/8" NPT.
- Customised capacity, strokes, Collar threading and tilting saddle available on request.
- QCC with Plastic dust cap. Aluminum dust cap on request.
Application :
Technical Specification :
These jacks are an excellent choice for maintenance, positioning, bending, pressing, ideal for wide range of applications at construction site, mills, railway workshops, power plants and industrial maintenance.
Technical Specification :
|
MODEL NO.
|
Capacity
|
Closed Ht. 'CH'
|
Stroke 'S'
|
Ram Dia 'RD'
|
Outer Dia 'D'
|
Oil Volume
|
Approx Weight
|
Suitable Hand Pump
|
|
tons.
|
mm
|
mm
|
mm
|
mm
|
cc
|
kgs.
|
||
|
LPS10/50
|
10
|
140
|
50
|
38
|
65
|
88
|
3
|
PHP 200/2
|
|
LPS10/100
|
10
|
190
|
100
|
38
|
65
|
164
|
3.5
|
PHP 200/2
|
|
LPS 10/150
|
10
|
240
|
150
|
38
|
65
|
243
|
4.9
|
PHP 200/2
|
|
LPS 15/50
|
15
|
150
|
50
|
45
|
70
|
131
|
3.5
|
PHP 200/2
|
|
LPS 15/100
|
15
|
200
|
100
|
45
|
70
|
247
|
4.6
|
PHP 200/2
|
|
LPS 15/150
|
15
|
250
|
150
|
45
|
70
|
366
|
5.2
|
PHP 200/2
|
|
LPS-20/50
|
20
|
160
|
50
|
50
|
80
|
155
|
4.9
|
PHP 200/2
|
|
LPS 20/100
|
20
|
210
|
100
|
50
|
80
|
324
|
5.7
|
PHP 200/2
|
|
LPS 20/150
|
20
|
260
|
150
|
50
|
80
|
480
|
7.1
|
PHP 200/3
|
|
LPS 25/50
|
25
|
170
|
50
|
60
|
90
|
156
|
6.8
|
PHP 200/2
|
|
LPS 25/100
|
25
|
220
|
100
|
60
|
90
|
404
|
8.2
|
PHP 200/3
|
|
LPS 25/150
|
25
|
270
|
150
|
60
|
90
|
596
|
10.2
|
PHP 200/3
|
|
LPS 30/50
|
30
|
170
|
50
|
65
|
100
|
251
|
8.0
|
PHP 200/3
|
|
LPS 30/100
|
30
|
220
|
100
|
65
|
100
|
528
|
10.5
|
PHP 200/3
|
|
LPS 30/150
|
30
|
270
|
150
|
65
|
100
|
779
|
14.5
|
PHP 200/3
|
|
LPS 50/50
|
50
|
185
|
50
|
80
|
130
|
425
|
17.0
|
PHP 500/3
|
|
LPS 50/100
|
50
|
235
|
100
|
80
|
130
|
817
|
19.4
|
PHP 500/6
|
|
LPS 50/150
|
50
|
285
|
150
|
80
|
130
|
1209
|
22.5
|
PHP 500/6
|
|
LPS 75/50
|
75
|
200
|
50
|
95
|
155
|
622
|
23.0
|
PHP 500/6
|
|
LPS 75/100
|
75
|
250
|
100
|
95
|
155
|
1188
|
28.5
|
PHP 500/6
|
|
LPS 75/150
|
75
|
300
|
150
|
95
|
155
|
1753
|
32.5
|
PHP 500/6
|
|
LPS 100/50
|
100
|
215
|
50
|
120
|
175
|
830
|
36.05
|
PHP 500/6
|
|
LPS 100/100
|
100
|
265
|
100
|
120
|
175
|
1616
|
40.6
|
PHP 500/6
|
|
LPS 100/150
|
100
|
315
|
150
|
120
|
175
|
2386
|
47.3
|
PHP 500/6
|
|
LPS 150/100
|
150
|
275
|
100
|
140
|
226
|
2383
|
65.0
|
PHP 500/6
|
|
LPS 150/150
|
150
|
325
|
150
|
140
|
226
|
3518
|
75.0
|
PHP 500/12
|
|
LPS 200/100
|
200
|
290
|
100
|
160
|
256
|
3141
|
88.0
|
PHP 500/12
|
|
LPS 200/150
|
200
|
340
|
150
|
160
|
256
|
4874
|
100.0
|
PHP 500/12
|
|
LPS 250/100
|
250
|
295
|
100
|
180
|
286
|
3991
|
115.0
|
PHP 500/12
|
|
LPS 250/150
|
250
|
345
|
150
|
180
|
286
|
5892
|
131.0
|
PHP 500/12
|
|
LPS 300/100
|
300
|
310
|
100
|
200
|
315
|
4746
|
148.0
|
PHP 500/12
|
|
LPS 300/150
|
300
|
360
|
150
|
200
|
315
|
7012
|
167.0
|
PHP 500/20
|
|
LPS 400/100
|
400
|
330
|
100
|
220
|
355
|
6465
|
200.0
|
PHP 500/20*PP
|
|
LPS 400/150
|
400
|
380
|
150
|
220
|
355
|
9544
|
225.0
|
PHP 500/20*PP
|
|
LPS 500/100
|
500
|
350
|
100
|
250
|
405
|
7925
|
281.2
|
PHP 500/20*PP
|
|
LPS 500/150
|
500
|
400
|
150
|
250
|
405
|
11700
|
315.0
|
PHP 500/20*PP
|
*PP - Power Pack
