We are Manufacturer, Supplier, Exporter of: Hydraulic Wedge Spreaders (HWS-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Light weight, compact, easy to use.
- Single acting spring return
- Cylinder honed to a surface finish of 0.4 microns
- Wedge spreaders avoid chisels, hammers, chain pulley block slings etc.
- Noiseless operation
- Stepped blocks are provided to increase wedge opening up to 80 mm.
- 6 mm access is enough for insertion
- Stepped arm capable of full load on each step.
- Tandem operation for even spreading
Remove all nuts before operation
Technical Specification :
Model No. |
Capacity |
Jaws Closed |
Jaws Open |
Weight |
Suitable Hand Pump |
tons. |
mm. |
mm. |
kgs. |
||
HWS-8 |
8 |
6 |
80 |
7 |
PHP-200/2* |
HWS-14 |
14 |
6 |
80 |
8 |
PHP-200/2* |
