Capacity : 4-30 tons, Stroke : 60-111 mm
We are Manufacturer, Supplier, Exporter of: Hydraulic In-Built Pump Pullers from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Self-Centering Mechanical Easy Puller (2/3 ARM)
|
Capacity
(tons) |
model
no
|
Reach Max
(mm)
|
Spread
Max (mm)
|
Weight
(kgs) |
|
5
|
PM
105
|
160
|
270
|
4.3
|
|
8
|
PM
125
|
210
|
300
|
6.1
|
|
10
|
PM
155
|
250
|
380
|
9.6
|
Hydraulic Pullers (2/3 ARM)
Capacity (tons) |
Model no |
Reach Max (mm) |
Spread Max (mm) |
Stroke (mm) |
Weight (mm) |
4 |
PM 400* |
185 |
255 |
60 |
4.5 |
6 |
PM 600* |
220 |
330 |
70 |
5.5 |
8 |
PM 800* |
230 |
350 |
85 |
6.5 |
12 |
PM 1200* |
270 |
375 |
85 |
8.0 |
20 |
PM 200* |
360 |
520 |
111 |
22.0 |
30 |
PM 3000* |
360 |
550 |
111 |
32.0 |
Cross Bearing Puller Excluding Pump
Capacity (tons) |
Model no |
Reach Max (mm) |
Spread Max (mm) |
Stroke (mm) |
Weight (mm) |
4 |
PME 400* |
190 |
315 |
60 |
8.5 |
6 |
PME 600* |
230 |
390 |
70 |
9.8 |
8 |
PM 800* |
280 |
460 |
85 |
14.8 |
12 |
PME 1200* |
300 |
515 |
85 |
14.8 |
20 |
PME 200* |
325 |
520 |
111 |
25.7 |
30 |
PME 3000* |
415 |
620 |
111 |
36.0 |
Cross Bearing Puller
Capacity (tons) |
Model no |
Set excluding Hyd. pump |
Reach Max (mm) |
Spread Min /Max Dia (mm) (mm) |
Weight (kgs) |
4 |
PM 410* |
P412 |
250 |
55-110 |
6.5-8.5* |
6 |
PM 610* |
P612 |
270 |
95-180 |
8.5-10.5* |
8 |
PM 810* |
P812 |
270 |
95-220 |
9.5-12.5* |
12 |
PM 1210* |
P1212 |
380 |
225-290 |
13.0-18.0* |
Tri - section Plates
Capacity (tons) |
Model no |
Reach Max (mm) |
Spread Max Dia (mm) |
Stroke (mm) |
Weight (kgs) |
12 |
PR 1200 |
270 |
375 |
85 |
14.0 |
20 |
PR 2000 |
360 |
520 |
111 |
20.0 |
30 |
PR 3000 |
360 |
550 |
111 |
30.0 |
Hydraulic Puller with Separate Pump ( 2/3 ARM )
Capacity (tons) |
Model no |
Available Shift Dia |
Spread Max Dia (mm) |
Weight (kgs) |
|
Min (mm) |
Max (mm) |
||||
6 |
ET3-160 |
26 |
160 |
215 |
3.5 |
8 |
ET3-210 |
50 |
210 |
280 |
5.5 |
20 |
ET3-340 |
90 |
340 |
460 |
18.0 |
30 |
ET3-495 |
140 |
495 |
660 |
45.0 |
