Capacity : 10 - 500 tons, Stroke : 50 - 150 mm, Working : 700 bar ( Max )
We are Manufacturer, Supplier, Exporter of: Threaded Ram, Spring Return Hydraulic Jacks (LTS-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Hight strength, Heat treated alloysteel body
- Blackodised ram.
- Hight pressure long life seals.
- Single acting spring return for smooth lowering. Threaded ram with mechanical safety lock-nut to sustain load on lock-nut for longer period
- Bottom mounting holes for bolting.
- Port Size 3/8" NPT.
- Adequate gripping by grooved saddle
- Adequate gripping by grooved saddle
- Custom strokes and tilting saddle available on request
- Aluminum dust cap on request
Application :
Technical Specification :
These jacks are an excellent choice for maintenance ideal for wide range of applications at construction site, mills, kiln lifting in steel, cement & process plants railway workshops, power plants, transformer lifting and industrial maintenance where lifted load is kept for longer period.
Technical Specification :
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Oil Volume |
Approx Weight |
Suitable Hand Pump
|
tons. |
mm. |
mm. |
mm. |
mm |
cc. |
kgs. |
||
LTS 10/50 |
10 |
160 |
50 |
40 |
65 |
80 |
3 |
PHP 200/2 |
LTS 10/100 |
10 |
210 |
100 |
40 |
65 |
164 |
4.5 |
PHP 200/2 |
LTS 10/150 |
10 |
260 |
150 |
40 |
65 |
243 |
5.5 |
PHP 200/2 |
LTS 15/50 |
15 |
170 |
50 |
45 |
70 |
119 |
4.2 |
PHP 200/2 |
LTS 15/100 |
15 |
220 |
100 |
45 |
70 |
247 |
5.0 |
PHP 200/2 |
LTS 15/150 |
15 |
270 |
150 |
45 |
70 |
366 |
6.0 |
PHP 200/2 |
LTS 20/50 |
20 |
180 |
50 |
55 |
80 |
116 |
6.0 |
PHP 200/2 |
LTS-20/100 |
20 |
230 |
100 |
55 |
80 |
324 |
7.0 |
PHP 200/2 |
LTS 20/150 |
20 |
280 |
150 |
55 |
80 |
480 |
8.0 |
PHP 200/3 |
LTS 25/50 |
25 |
200 |
50 |
65 |
90 |
192 |
8.0 |
PHP 200/2 |
LTS 25/100 |
25 |
250 |
100 |
65 |
90 |
404 |
10.0 |
PHP 200/3 |
LTS 25/150 |
25 |
300 |
150 |
65 |
90 |
596 |
11.5 |
PHP 200/3 |
LTS 30/50 |
30 |
200 |
50 |
70 |
100 |
276 |
10.0 |
PHP 200/2 |
LTS 30/100 |
30 |
250 |
100 |
70 |
100 |
528 |
12.0 |
PHP 200/3 |
LTS 30/150 |
30 |
300 |
150 |
70 |
100 |
779 |
14.5 |
PHP 200/3 |
LTS 50/50 |
50 |
215 |
50 |
85 |
130 |
432 |
23.0 |
PHP 500/6 |
LTS 50/100 |
50 |
265 |
100 |
85 |
130 |
870 |
21.5 |
PHP 500/6 |
LTS 50/150 |
50 |
315 |
150 |
85 |
130 |
1209 |
25.3 |
PHP 500/6 |
LTS 75/50 |
75 |
230 |
50 |
95 |
156 |
566 |
26.0 |
PHP 500/6 |
LTS 75/100 |
75 |
280 |
100 |
95 |
156 |
1188 |
26.4 |
PHP 500/6 |
LTS 75/150 |
75 |
300 |
150 |
95 |
156 |
1753 |
38.0 |
PHP 500/6 |
LTS 100/50 |
100 |
250 |
50 |
120 |
176 |
770 |
62.0 |
PHP 500/6 |
LTS 100/100 |
100 |
300 |
100 |
120 |
176 |
1616 |
45.0 |
PHP 500/6 |
LTS 100/150 |
100 |
350 |
150 |
120 |
176 |
2386 |
55.0 |
PHP 500/6 |
LTS 150/1006 |
150 |
315 |
100 |
140 |
226 |
2383 |
80.0 |
PHP 500/6 |
LTS 150/150 |
150 |
365 |
150 |
140 |
226 |
3518 |
95.0 |
PHP 500/12 |
LTS 200/100 |
200 |
330 |
100 |
160 |
256 |
3300 |
110.0 |
PHP 500/12 |
LTS 200/150 |
200 |
380 |
150 |
160 |
256 |
4874 |
125.0 |
PHP 500/12 |
LTS 250/100 |
250 |
345 |
100 |
180 |
286 |
3991 |
150.0 |
PHP 500/12 |
LTS 250/150 |
250 |
395 |
150 |
180 |
286 |
5892 |
160.0 |
PHP 500/12 |
LTS 300/100 |
300 |
360 |
100 |
200 |
315 |
4746 |
190.0 |
PHP 500/12 |
LTS 300/150 |
300 |
410 |
150 |
200 |
315 |
7012 |
204.0 |
PHP 500/16 |
LTS 400/100 |
400 |
400 |
100 |
220 |
355 |
6465 |
252.0 |
PHP 500/20*PP |
LTS 400/150 |
400 |
450 |
150 |
220 |
355 |
9544 |
285.0 |
PHP 500/20*PP |
LTS 500/100 |
500 |
425 |
100 |
250 |
405 |
7925 |
373.0 |
PHP 500/20*PP |
LTS 500/150 |
500 |
475 |
150 |
250 |
405 |
11699 |
350.0 |
PHP 500/20*PP |
