Capacity : 600 - 1000 tons, Stroke : 100 - 150 mm, Working : 700 bar ( Max )
We are Manufacturer, Supplier, Exporter of: Plain Ram, Load Return Hydraulic Jacks ( PLR - Series ) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- High strength, Heat treated alloy steel body.
- Hard chrome plated ram to resist scoring and corrosion.
- Single acting load return.
- High pressure long life seals. QCC with dust cap.
- Adequate gripping by grooved saddle.
- Bottom mounting holes for bolting.
- Customised higher capacity, strokes, collar threading and tilting saddle available on request.
- QCC with Plastic dust cap. Aluminum Dust Cap on Request.
- Port Size 3/8" NPT.
Application :
Technical Specification :
These jacks are ideally used for lifting of girders, pile testing for bridges and building foundation, handling of heavy duty machineries, steel fabrication and ship building etc.
Technical Specification :
MODEL NO. |
Capacity |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Oil Volume |
Approx Weight |
Suitable Hand Pump
|
tons. |
mm. |
mm. |
mm.
|
mm. |
cc. |
kgs. |
||
| PLR 600 / 100 | 600 | 395 | 100 | 280 | 440 | 9534 | 380 | PHP 500 / 16*PP |
| PLR 600 / 150 | 600 | 445 | 150 | 280 | 440 | 14073 | 430 | PHP 500 / 16*PP |
| PLR 800 / 100 | 800 | 400 | 100 | 300 | 510 | 12544 | 540 | *PP |
| PLR 800 / 150 | 800 | 450 | 150 | 300 | 510 | 18516 | 600 | *PP |
| PLR 1000 / 100 | 1000 | 470 | 100 | 350 | 570 | 17700 | 800 | *PP |
| PLR 1000 / 150 | 1000 | 520 | 150 | 350 | 570 | 24652 | 860 | *PP |
